Pixfra Mile 2 M20 M215M Thermal Imaging Monocular 256x192 - 15mm

Pixfra Mile 2 M215M Thermal 256x192 Imager - 15mm. The Mile 2 M215M thermal imaging monocular packs a powerful punch for such a compact and lightweight device. With a 256×192, 12μm, <35mK NETD thermal sensor and a powerful 15mm f1.0 objective lens, this monocular will reveal even the smallest heat signature at a range of up to 800m. Plus, with a strong Wi-Fi connection, this device can connect to up to four smart devices, allowing for effortless group sharing at a range of up to 40m. This version of the Mile 2 M215 features manual focus control.

Pristine Image Clarity

The Pixfra Mile 2 M215M thermal imaging monocular features a sensitive 256×192,12μm, <35mK NETD thermal sensor and a powerful 15mm f1.0 objective lens, revealing even the smallest heat signature at a range of up to 800m.

Effortlessly revealing an animal’s important anatomical features in vivid detail crystal-clear, this thermal imaging monocular will present stunning images onto an 800×600, 0.32”, OLED display.

Compact & Slimline Design

The Mile 2 series features a completely new, slimline design which seamlessly incorporates the power button into the Pixfra logo on the side of the device — reducing the number of buttons along the top of the monocular and offering simplified operation of digital functions.

The Mile 2 M215M remains extremely compact and much more lightweight than previous iterations, allowing for comfortable observation over long periods and easy transportation when not in use, fitting nicely into a pack or pocket.

Plus, with a variety of convenient accessories, including a soft pouch, neck strap, and wrist strap included, the Mile 2 M215M will remain comfortable to use and carry.

Reliable in Any Weather
The Mile 2 M215M will ensure a powerful performance in any weather condition thanks to its IP67 rating, protecting the device against dust and water ingress. This certification also ensures the device remains unaffected in adverse weather conditions such as heavy rain and fog, and continues to work seamlessly in environments with ≤95% humidity or extreme temperatures from –30 to +55 °C.

Long-Life Battery for Hours of Observation
The Mile 2 M215M features a rechargeable long-life battery, providing up to 8.5 hours of effective power on a single charge (depending on temperature), keeping observations going through the day and well into the night.

Seamless Connectivity
With a stable and reliable Wi-Fi connection, the Mile 2 M215M will achieve seamless connectivity to a smartphone or tablet via the free Pixfra app for Android and iOS devices. This opens up greater observation capabilities, including group observations via live view on a connected mobile phone or tablet, with a range of up to 40m and the ability to connect to up to four different smart devices.

Features:

• 256×192,12μm, <35mK NETD thermal sensor
• 15mm f1.0 objective lens
• 800m detection range
• Built-in video recording
• Built-in Wi-Fi
• Seamless connectivity of up to 4 smart devices
• Manual focus control

• Thermal Sensor 256×192, 12μm, <35mK NETD
• Objective Lens 15mm f1.0
• Spectral Range 8 μm–14 μm
• Field of View H: 11.7°; V: 8.8°/H: 20.5 m; V: 15.4 m (@100 m)
• Focus Control Manual
• Close Focus Distance 2.6 m (8.53 ft)
• Detection Range Up to 800 m
• Magnification 2.33x
• Frame Rate 50 Hz
• Display 800 × 600, 0.32 inch OLED
• Color Palettes 6 (white hot/black hot/iron red/alarm/emerald/amber)
• Video Compression H.264
• Diopter –3 D to +1 D
• Eye Relief 13 mm (0.51 inch)
• Exit Pupil 5 mm (0.20 inch)
• Digital Zoom 1×, 2×, 4×, 8×
• Video Recording Yes
• Still Image Capture Yes
• Wi-Fi Hotspot Yes
• Hot Spot Tracking Yes
• Video Distance Measurement Yes
• FFC Calibration Auto, Manual, External Correction
• Standby Mode Yes
• DPC (Defective Pixel Correction Yes
• Storage Built-in 16GB
• Battery Type Rechargeable Lithium Battery
• Battery Life 8.5 hours (@ 25°C)
• Power Supply 5 VDC/2 A
• Port USB Type-C
• Overvoltage Protection Yes
• Operating Temperature –30 to +55 °C (–22 to +131 °F)
• Operating Humidity ≤95%
• Protection Grade IP67
• Packaging Dimensions 180.0 mm × 123.0 mm × 96.0 mm (7.09″ × 4.84″ × 3.78″) (L × W × H)
• Product Dimensions 155.3 mm × 56.6 mm × 50.3 mm (6.12″ × 2.23″ × 1.98″) (L × W × H)
• Gross Weight 760 g (1.68 lb)
• Net Weight 270 g (0.60 lb)
